ELI 380 Resting Electrocardiograph
In Stock
Usually ships in Drop Ship
Sale:
$25,947.89
1
/ Each
Recommended Accessories
Ask an expert
Buy with confidence.
Contact our experts today.
Buy with confidence.
Contact our experts today.
Description
The Welch Allyn ELI 380 Resting Electrocardiograph is an efficient and non-invasive testing solution that detects and records known cardiovascular abnormalities and diseases including arrhythmias, evidence of coronary heart disease, and left ventricular hypertrophy.
Awesome Design. Made with a chemically strengthened, glass-capacitive 17" LCD touchscreen display, the ELI 380 Resting Electrocardiograph increases a medical professional's overall workflow and the accuracy & security of the data acquired. This allows hassle-free navigation from any angle and is built to last for years to come. The ECG Machine also promotes a cleaner and safer environment for the patient and medical staff by eliminating the use of traditional keyboards.
Reliable Results. The ELI 380 Resting Electrocardiograph has partnered with the FDA to build one of the largest cloud-based repositories of clinical data in the world with more than 10 million resting ECGs which are all analyzed by the VERITAS Algorithm. The simplified workflow decreases overall exam time and aids in the prevention of manual entry mistakes. Built to be portable, the Resting ECG uses up to two lithium-ion batteries which increases the overall usage and time between charging while also reducing the frequency of battery replacement. It has a built-in wireless module and antenna for hassle-free transport of patient data. The unique WAM (Wireless Acquisition Module) allows full diagnostic quality with a sampling rate of 40,000 samples per second per channel and eliminates the use of cables.
Designed with Your Needs in Mind: With a 180° swivel and 120° tilt capability, the ERGO screen moves with you, so exams can be performed without leaving your patient’s side. The capacitive touchscreen helps make navigation easy from any angle, and eliminates the need to clean a traditional keyboard—which has difficult-to-reach nooks and crannies—promoting a more sanitary, safer environment for your patients and staff. And with a calibration-free, chemically strengthened glass surface, our touchscreen is built to last.
Features
- Streamlined barcode workflow eliminates steps and reduces manual entry.
- Glass surfaces on the capacitive touchscreen display simplify cleaning.
- Best 10 feature captures the cleanest 10 seconds of ECG data from memory, which can help reduce the need for repeat ECGs.
- Follows ACC, AHA and HRS recommendations for baseline filtering (0.05 Hz).
- Exceeds ACC, AHA and HRS upper frequency cutoff (300 Hz) for adults and children.
- DoD-approved security features safeguard patient health information (PHI) and your network.
- Critical Test Results help quickly identify high-risk patients.
- Mobile ECGs with Wireless Acquisition Module (WAM).
- Acquire 12-lead or 15-lead ECGs.
Product Specifications
| EMR Compatible: | Yes |
|---|---|
| PC Compatible: | Yes |
| Printer: | Yes |
| Dimensions: | 20" L x 15.5" W x 5.5" H |
| Weight: | 27 lbs |
| Display Type: | 17" LCD Capacitive Touchscreen |
| Operating Humidity: | 10% to 95% RH, non-condensing |
| Safe Operating Temperature: | +50 deg. to +104 deg. F |
| Safe Storage Temperature: | -40 deg. to +158 deg. F |
| Storage Humidity: | 10% to 95% RH, non-condensing |
| Filters: | Low-pass filters 40 Hz, 150 Hz, or 300 Hz; AC interference filter 50/60 Hz; High-performance baseline filter |
| Frequency Range: | 0.05 to 300 Hz |
|---|---|
| Sampling Rate: | 40,000 s/sec/channel used for pacemaker spike detection; 1000 s/sec/channel used for recording and analysis |
| Memory Capacity: | Up to 500 ECGs |
| Battery Life: | Up to 7 Hours |
| Power Source: | 110VA Power Supply; Internal rechargeable battery |
| Print formats: | Standard or Cabrera |
| Print speeds: | 5, 10, 25 or 50 mm/s |
| Electrodes Standards & Certifications: | Meets or exceeds the requirements of ANSI/AAMI ES 60601-1 |
| Patient Cable and Leads Standards & Certifications: | Meets or exceeds the requirements of ANSI/AAMI/IEC 60601-2-25 |
| Warranty: | 2 Years |
| CA Prop 65 Warning: | Yes |
